Exynos 1080 is a 5nm Smartphone Chipset for Upcoming flagship

After a lot of speculation, Samsung has officially announced its much talked about Exynos 1080 chipset through an event in China. It is the successor to last year’s Exynos 980 and the 1080 chipset has a slightly higher position than the exynos 980 in terms of performance as it can see some notable gains in features compared to the 980 processor. It should be remembered that this is a “premium” SoC, which means that it is not a fully flagship SoC, although it is largely a middle-class and flagship category, fitting itself in between these two categories.

The Exynos 1080 is built using Samsung 5nm LPE process, so it is highly power-efficient. This mobile chipset is defined by having a new 1+3+4 CPU configuration, full 5G connectivity integrated and reasonably large GPU. it uses four ARM Cortex-A55 CPU cores, all these cores are clocked at 2.0GHz and handle light tasks, There are four Cortex-A78 CPU cores for performance tasks and one of those cores is run on 2.8GHz, while remaining three Cortex-A78 cores are runs on 2.6GHz.

While focusing on the GPU, the new SoC also features the Mali-G78 MP10 GPU, we are seeing a fairly good improvement compared to the Exynos 980 as Samsung is now not only incorporating the new Mali-G78 architecture, but also doubling deployment of the core. it gives almost the same performance as the Exynos 990 that was added to Samsung’s Note 20 Ultra. The processor’s support for refresh rates of up to 144Hz in Full HD+ or QHD+ displays with a 90Hz refresh rate.

The camera ISP (image signal processor) capabilities have been improved, supporting for resolutions of up to 200MP (single camera sensor), and dual-sensor operation up to 32MP + 32MP, it also have the ability to capture up to 4K 60fps and HDR10+ video recording.

The Exynos 1080 SoC is supports LPDDR5 and UFS v3.1 Memory chips. The integrated NPU inside the Exynos 1080 make it capable of running up to 5.7 TOPS. Take a look at other features of this SoC, this includes Bluetooth 5.2, dual-band Wifi 6, GPS and USB Type-C port.

It has also been announced by Samsung that this chipset will be used for the first time in vivo flagship smartphone which is likely to be launched by the end of this year. whenever a new update or smartphone release with exynos 1080 SoC, then we will provide a full specification, price, and more.



SpecsExynos 1080Exynos 980
CPU CoreOcta-core CPUOcta-core CPU
CPU
Architecture
1×2.8Ghz (Cortex A78)
3x 2.6GHz (Cortex A78)
4x 2.0GHz (Cortex A55)
2x 2.2GHz (Cortex A77)
6x 1.8GHz (Cortex A55)
CPU
Clock Speed
Up to 2.8GHzUp to 2.2GHz
Process
Technology
5nm LPE8nm LPP
GPUMali-G78MP10Mali G76MP5
NPUNPU + DSP
5.7TOPS
Integrated
ISPMain: 200MP
Dual : 32MP + 32MP
Main: 108MP
Dual : 20MP + 20MP
RAMLPDDR5 / LPDDR4XLPDDR4X
Camera
Capability
Up to 200MPUp to 108MP
Video
Capability
4K @ 60 FPS
H.265/HEVC, H.264, VP9
4K @ 120 FPS
H.265/HEVC, H.264, VP9
ChargingAdaptive Fast ChargingQuick Charge 4+
Quick Charge AI
WiFi SupportWi-Fi 6-readyWi-Fi 6-ready
Modem(5G NR Sub-6)
5100 Mbps Download
1280 Mbps Upload



(5G NR mmWave)
3670 Mbps Download
3670 Mbps Upload

(5G NR Sub-6)
2550 Mbps Download
1280 Mbps Upload
